PD9100L-Series
PD9145AL-Lithium
PD9170L
PD9180L-Lithium
PD9100L-Engineered
Standard-Features
  • Reverse battery protection protects converters from damage resulting
    from improper (reverse) battery lead connection.
  • Units deliver filtered DC power to the Lithium Ion Batteries to ensure
    their built-in electronic balancing circuits operate properly.
  • Electronic current limiting automatically reduces output voltage when
    maximum capacity is exceeded. Protects your investment.
  • Low line voltage protection automatically shuts converter down if input voltage is insufficient.
  • Variable speed intelligent cooling fan automatically monitors converter
    temperature and activates fan at speed required.
  • High voltage protection protects converter from spikes or surge of voltage over 135V.
  • Automatic thermal protection reduces converter output to safe levels when unit temperature exceeds pre-set limits and protects converter
    from damage due to excessive heat.
  • Output Voltage can be FACTORY ADJUSTED to meet OEM requirements for various Lithium Ion Battery chemistries and voltages. Standard “L”
    series voltages are set for 14.6/28.55 volts to meet requirements for
    Lithium Iron Phosphate Batteries. Other chemistries may require
    different voltages.
  • The PD9100L Series can be wired in parallel to charge at much higher current rates. They can also be wired in series/parallel to charge 36, 48,60, 72 and higher voltage battery packs at high charge rates.
  • 2 year limited warranty.

Lithium Ion Batteries require special balancing circuits and chargers!

12-Volt Lithium Ion Batteries are composed of 4 cells, each with a voltage rating of 3.2-volts wired in series providing a total output of 12.8 Volts. Lithium Iron Phosphate type cells are the safest and most common type used,
however, they must never be charged to a voltage over 4-Volts and must never be discharged below 2-volts, or they will be damaged.
Due to manufacturing inconsistencies, each Lithium Ion Cell is different (i.e. they will each charge and discharge at different rates). These cell
differences make recharging Lithium Batteries fairly complex and requires that the battery manufacturer install electronic balancing circuits inside the battery to prevent overcharging a cell, or discharging too much. While these balancing circuits protect the cells, they can increase recharge times, depending on the mix of cells in each 12-volt battery pack. This increase in recharge time is especially apparent in higher voltage and or higher
current battery packs. Lithium Ion Batteries also require battery chargers that can produce ahigher voltage than provided by standard 12-volt or 24-volt lead/acid battery chargers. Trying to recharge a Lithium Ion Battery with a standard lead/acid charger will result in a partially charged battery and
MAY REDUCE BATTERY LIFE!

PD9100L-Listing
Powering-Possibilities
Input: 105-130 VAC 50/60 Hz. 1300 Watts
Output: 14.6 Volts VDC 80-Amps
Dimensions: 9.15”L x 7.38”W x 3.6”H
Weight: 7.5 lbs.

Plugs into a 20 Amp outlet. Removal or alteration of converter
20 Amp power cord will void warranty.
Input: 105-130 VAC 50/60 Hz. 1000 Watts
Output: 14.6 Volts VDC 60-Amps
Dimensions: 9.15”L x 7.38”W x 3.6”H
Weight: 5.8 lbs.
Input: 105-130 VAC 50/60 Hz. 725 Watts
Output: 14.6 Volts VDC 45-Amps
Dimensions: 8.25”L x 7.25”W x 4.7”H
Weight: 4.5 lbs.
Input: 105-130 VAC 50/60 Hz. 1,300 Watts
Output: 28.55 Volts VDC 40-Amps
Dimensions: 9.15“L x 7.38”W x 3.6”H
Weight: 7.5 lbs.

Plugs into a 20 Amp outlet. Removal or alteration of converter 20 Amp power cord will void warranty.
Input: 105-130 VAC 50/60 Hz. 500 Watts
Output: 14.6 Volts VDC 30-Amps
Dimensions: 8.25”L x 7.25”W x 4.7”H
Weight: 4 lbs
Input: 105-130 VAC 50/60 Hz. 900 Watts
Output: 28.55 Volts VDC 25-Amps
Dimensions: 8.25”L x 7.25”W x 4.7”H
Weight: 4.5 lbs.

Product Information

Series Name Models coveredOwners / Installation ManualTroubleshooting GuideParts or accessories
PD9100L
Lithium Converter
PD9130L
PD9145L
PD9160L
PD9180L
English-Manual
French-Manual
Same as Model number.

Model Numbers

Model / Part NumberFeaturesReplaces
PD9100L
PD9100LV
Lithium Only Converter/ChargerPD91XXL
PD91XXLV
