AC Distribution PD5500 series.
AC Distribution Centers
Progressive Dynamics PD5500 Series AC Distribution PanelMODEL # | Description | Price | Buy It Now | ||
---|---|---|---|---|---|
![]() ![]() | ![]() | PD55K003A | A split 30/30 panel accepts — LEFT SIDE: 30 Amp main and up to 8 branch circuits — RIGHT SIDE: 30 Amp main and up to 8 branch circuits. With 2 7 position Neutral bars. Color is Black. Dimensions: 11.7″ W x 9.2″ H x 4.1″ D Cut-out Size: 10.5″ W x 7.5″ H Weight: 2 lbs. Compatible with 6000 Series DC Power Distribution Panel. Press open door for easy access to circuit breakers. AC Panel features 12 built-in push and lock strain relief connectors. Designed with large front wiring compartment. | $83.66 | Add to cart |
![]() ![]() | ![]() Enlarge | PD55K006 | A split 50/30 panel accepts — LEFT SIDE: dual 50 Amp main and up to 10 branch circuits — RIGHT SIDE: 30 Amp main and up to 4 branch circuits. Color is Black Dimensions: 11.7″ W x 9.2″ H x 4.1″ D Cut-out Size: 10.5″ W x 7.5″ H Weight: 2 lbs. Compatible with 6000 Series DC Power Distribution Panel. Press open door for easy access to circuit breakers. AC Panel features 12 built-in push and lock strain relief connectors. Designed with large front wiring compartment. | $83.66 | Add to cart |
![]() | 813110 | Optional 15 amp outlet for the back of the PD5500 panels. | 5.95 | Add to cart |
