PD9100-Series
PD9100-Converter
TCMS-Charge-Wizard-Port
PD9100-Models
PD9105V-Wizard
PD9100L-Features
  • Equipped with 15 Amp electrical cord.
    (with the exception of the 80 Amp models)
  • Reverse battery protection protects converters from damage resulting from improper (reverse) battery lead connection.
  • These solid-state converter/chargers deliver filtered DC power for safe and reliable service.
  • Electronic current limiting automatically reduces output voltage when maximum capacity is reached.
    Protects your investment.
  • Variable speed intelligent cooling fan automatically monitors converter temperature and activates fan at speed required. Very slow quiet speeds are used when demand is low such as during sleeping hours.
  • High voltage protection protects converter from spikes or surge of voltage over 135V.
  • Automatic thermal protection reduces converter output to safe levels when unit temperature exceeds pre-set limits and protects converter from damage due to excessive heat.
  • Built-in Total Charge Management System® (TCMS) connector accepts the optional Charge Wizard that constantly monitors voltage status and automatically manages
    your battery.
  • 2 year limited warranty.
PD9100L-Listing
PD9180-R_outlined_med res
80-Amp-PD9100
  • Input: 105-130 VAC, 50/60 Hz, 1300 Watts
  • Output: 13.6 VDC, 80 Amp
  • Dimensions: 9.15”L x 7.38”W x 3.6”H
  • Weight: 7.5 lbs.
20-Amp-Outlet
PD9170A-R_med res
  • Input: 105-130 VAC, 50/60 Hz, 1250 Watts
  • Output: 13.6 VDC, 70 Amp
  • Dimensions: 9.15”L x 7.38”W x 3.6”H
  • Weight: 5.8 lbs.
PD9160A-R
60-Amp-PD9100
  • Input: 105-130 VAC, 50/60 Hz, 1000 Watts
  • Output: 13.6 VDC, 60 Amp
  • Dimensions: 9.15”L x 7.38”W x 3.6”H
  • Weight: 5.8lbs.
PD9145A 45 Amp Electronic Power Converter, battery charging system
45-Amp-PD9145
  • Input: 105-130 VAC, 50/60 Hz, 725 Watts
  • Output: 13.6 VDC, 45 Amp
  • Dimensions:8.25”L x 7.25”W x 4.5”H
  • Weight: 4.5lbs.
PD9130 Electronic Power Converter for charging RV batteries.
30-Amp-PD9100
  • Input: 105-130 VAC, 50/60 Hz, 500 Watts
  • Output: 13.6 VDC, 30 Amp
  • Dimensions: 8.25”L x 7.25”W x 4.5”H
  • Weight: 4.0lbs.
Plug-In-Charge-Wizard
Powering-Possibilities

Product Information

Series Name Models coveredOwners / Installation ManualTroubleshooting GuideParts or accessories
PD9100 Converter

PD9130
PD9140
PD9145A
PD9160A
PD9170
PD9180A
English-Manual
French-Manual
PD9100/9200 Troubleshooting

Youtube Video
Same as Model number
PD9100L
Lithium Converter
PD9130L
PD9145L
PD9160L
PD9180L
English-Manual
French-Manual
Same as Model number.

Model Numbers

Model / Part NumberFeaturesReplaces
PD9180A80 Amp Converter Charger.
PD9201 Wizard Sold Separately
OEM model
PD9180 Newer models are smaller.
PD9180AV
PD9170A70 Amp Converter Charger.
PD9201 Wizard Sold Separately
In a Retail Box
PD9170
PD9170
PD9170AV
PD9160A60 Amp Converter Charger.
PD9201 Wizard Sold Separately
In a Retail Box
PD9160AV
PD9160ALV60 Amp Converter Charger.
For Lithium only.
PD9160AL
PD9160AV60 Amp Converter Charger.
PD9201 Wizard Sold Separately
In a Retail Box
PD9160A
PD9100L
PD9100LV
Lithium Only Converter/ChargerPD91XXL
PD91XXLV
